NEO PQA 7000 - Mobile Power Quality Analyzer

As the year progresses NEO Messtechnik continues to evolve and demonstrates once again the ability to forge its long-standing expertise of the Power Quality market into yet another impressive PQ Analyzer that enables engineers to stay ahead of the curve.

4 Key figures

At a Glance

Sampling Rate

48 kS/s

Bandwidth

20 kHz

Accuracy

0.05 %

Resolution

24-bit

Alt Text

Powerful software

.. that doesn’t stand in your way

Direct measurement data monitoring on the device (oscilloscope, FFT, vector, recorder, etc.)

Powerful data evaluation (overlay of several measurement files, multi-quantile calculation, report generation according to various standards). standards in post-processing like EN50160, IEC61000-2-2, export options etc.).

Synchronization of multiple devices (incl. PMU function)

Precise measurements

High-frequency voltage and current (20 kHz) measurements
with 0.05 % accuracy and up to 48 kS/s

with current sensors of your choice
Rogowski, clamps, ..

7″ Multi-touch display – or completely without a display

plus 256GB data storage that is extendable

Alt Text

REMOTE CONNECTION AND MULTIPLE DEVICE SYNCHRONISATION

Endless possibilites

Large data storage

256 GB from the get-go and extendable depending on your specific application needs!

Easy Remote-Connection

access single devices for monitoring and configuration purposes remotely (TeamViewer©, FastViewer©)

We listened to engineers' 6 most common complaints about their current PQ analyser

The NEO Power Quality Blog

We wanted to know how experienced measurement engineers truly think and feel about their current power quality analyser. Read more about the 6 most common customer complaints and how
the NEO PQA 7000 answers all of them.

The NEO Sensor Integration

Highest Precision

Alt Text

HIGH BANDWIDTH & HIGH ACCURACY

Conventional PQ Analyzers, even if they are Class A certified, are not sufficient for modern measurement applications. We use the best available components to ensure the highest safety category and also the highest accuracy. NEO instruments offer high bandwidth (up to 1 MHz) and correct the frequency dependent behavior of current & voltage sensors as well as integrated electronics to achieve the best possible measurement results

SENSOR INTEGRATION

All current sensors offered by NEO Messtechnik are industry proven for different applications. We use and improve on the best available sensors in the market.

FREQUENCY DEPENDENT CALIBRATION
The NEO sensor integration calibrates each sensor over a wide frequency bandwidth and corrects frequency dependent phase shift and amplitude damping. This allows for high precision from DC to high-frequency measurements.

MEASUREMENT RANGE DEPENDENT CALIBRATION
In addition, the sensors will calibrated for each measurement range using multiple points. The calibration will typically cover points from 1% to 100% of the nominal measurement range. This will improve the accuracy and precision, especially at low current (e.g., 1% of nominal measurement range).

Alt Text
Alt Text

LEADING IN SAFETY

Overvoltages from power lines down to factories can be higher than normal operating voltages. To avoid any kind of electrical accident, NEO Messtechnik emphasizes the importance of a safe instrument design. For example, the high-voltage inputs of the PQA 8000 instrument (CAT IV 600V) are isolated up to 6kVp while maintaining high precision (0.05%) and high sampling (up to 1MS/s). This is world-leading technology.

Truly Intuitive Software

Clearly structured. Explicit Menus.

1. SETUP

The instrument has a clear structure that
shows schematics with explanations.

Alt Text
Alt Text

2. MEASURE

During measurements the user can define widgets such as Scopes, Vector Scopes, Harmonic FFTs, Tables, and Recorders.

3. ANALYSE

Sophisticated functions include PQ Data, Transients, Disturbances, and Alarms.

Alt Text

4. REPORT

The instrument can automatically generate reports and professional documentation. The user can create reports that include all relevant information (location, comments, company logo, etc) directly on-site or during post processing. PDF reports that are saved on the instrument are always available and can be shared directly via email.

Alt Text
Alt Text
Alt Text

5. EXPORT

Data can be exported into CSV, XLS, PDF, Comtrade, and PQDiff.

6. OTHER PROGRAMS

The instrument uses Microsoft Windows© as the operating system. Programs such as Microsoft Excel, Word or Matlab can be added as well as Email messaging services.

Key Features

Alt Text

according to IEC 61000-4-30 Ed.3 and IEC 62586

Harmonics, Interharmonics and THD:
Class A
Higher Frequencies (200Hz band):
2 – 9 kHz
Symmetrical Components & Unbalance:
Class A ((Pos-, Neg- and Zero Sequence))
Flicker (PST, PLT, Pinst) and RVC:
Class A

.

Voltage Events:
Class A (dip, swell, interruption – time, extrema, length)
Frequency:
10 sec, AVE, MIN, MAX
Voltage, Current:
RMS, AVE, MIN, MAX, ½ Period-values, 200ms, 10s, 10min
Time Synchronisation:
Class A

Alt Text

Power Calculation:
P, Q, S, PF, cos phi, D, DH, QH

Frequency:
10 sec, AVE, MIN, MAX

Voltage, Current:
RMS, AVE, MIN, MAX, ½ Period-values, 200ms, 10s, 10min

Power Calculation:
P, Q, S, PF, cos phi, D, DH, QH

Energy:
Total, positive, negative (P, Q, P+, P-, Q+, Q-)

Efficiency:
DC / AC, U-I Curve for PV

Wiring:
DC, 1-Phase, 2-Phase, 3-Phase Star and Delta

Alt Text

MIN, MAX, RMS, AVE:
U, I, P, Q, S, f, PF, phi, THD, Harmonics, Interharm., Unbalance, etc.
ENVELOPE / WINDOW:
U, I
DELTA:
dU, dI, df, dP, etc.

DERIVATE (RATE OF CHANGE):
dU/dt, df/dt etc. … per ms, number of periods or half-period
VOLTAGE SIGNALLING:
Threshold
EN50160:
Trigger on any EN50160 parameter (Max, Quantil)

Alt Text

1/2 PERIOD TRIGGER:
U, I, P, Q, S, f, PF, phi, THD, Harmonics, Interharm., Unbalance, etc.

SYMMETRICAL COMPONENTS:
Positive-, Negative-, Zerosequence

Phasor Measurement Unit (PMU)
according to IEEE C37.118: Total Vector Error 0.01% (typ.), Angle Error 0.003°(typ)

RATE OF CHANGE FREQUENCY (ROCOF)

POWER QUALITY, HARMONICS, FLICKER:
IEC61000-4-30 Ed. 3 Class A / IEC61000-4-7 / IEC61000-4-15 /  IEC62586-2 Ed. 2 / IEC62586-1
PUBLIC GRID, RAILWAY AND INDUSTRY
EN50160 / EN50163 / IEC61000-2-2 / IEC61000-2-4 (Class 1; 2; 3) / IEEE519  / IEEE 1159 / IEC61000-2-12 / NRS048
WIND POWER, RENEWABLES AND GRID CODES
IEC61400-21 / IEC61400-12 / FGW-TR3 / VDE N-4105 / VDE N-4100 / VDE N-4110 / D-A-CH-CZ / BDEW / ROCOF / IEEE C37.118-2005 (PMU)
MOTORS, TRANSFORMERS AND ELECTRICAL EQUIPMENT
IEC60034 / IEC 60076-1 / IEC61000-3-2 / IEC61000-3-3 / IEC61000-3-11 / IEC61000-3-12

APPLICATIONS

See all Applications of the NEO PQ Analyzers
